B&M HI-TEK Natural Aluminum Rear End Differential Cover For 10-BOLT CAR



Our engineers designed the line of Hi-Tek differential covers to not only look good but address a number of weaknesses of the factory stamped steel covers. First, they started by constructing the covers of thick A356.0-T6 aluminum, which dissipates heat much faster than the factory steel unit keeping the fluid temperature lower under high-stress loads vs. a steel cover. Then for added durability, we added a reinforced center bar for extra strength along with load bolts to help prevent bearing cap deflection under severe loads. The internal shape of the cover retains the smooth round back internally to help keep the fluid flow going over the ring gear to properly lubricate the gears and bearings. Additional features include a magnetic drain plug for catching ferrous metal particles, machined B&M logo, MIL-Spec (MIL-A-8625) black anodized finish, and all necessary hardware and easy to follow detailed instructions for a quick and simple installation you can do at home.

Note: Gasket not included

Designed to fit most vehicles with GM 8.2-inch, 8.5-inch & 8.6-inch 10-bolt differentials. However vehicles may have other interfering components that may require modifications or moving of existing brackets, require longer cover bolts or different cover bolts, clearance of sway bars etc. - Checking for adequate clearance and fitment for your application should be verified prior to purchase & installation. Refer to "Technical Specs Tap" and measurement drawings for specifications

PART NUMBER: SUS-926

•

B&M Performance & Off-Road has been at the vanguard of the growing automotive aftermarket since the early 1950s. Specializing in performance automatic transmissions and transmission components, B&M will help you put the power to the ground.
