1968 Camaro Dash Instrument Cluster & Console Gauges Set (VHX): Speedometer, Tachometer, Oil Pressure, Water Temp, Voltmeter and Fuel

Alternative Views:

Our Price: $973.75

PART NUMBER: DAS-1051

Face Style

Click to view another Choose Face

Choose Face*:

Face Lighting

Choose Lighting Color*:

Qty:

Description

Extended Information

1968 Camaro Dash Instrument Cluster & Console Gauges Set (VHX)

The first generation Camaro began an American legacy. The new VHX (Vehicle Hybrid Instrument Systems) system with console gauges will modernize your ride with the latest technology and styling. Attaching directly to the back side of the stock instrument housing, the fitment couldn’t be simpler. Fully lit needles, backlit faces, and highly visible LCD message centers are a few of the things that you can see which set the VHX Series apart from yesterday’s traditional approach to instrumentation. A few of the features which you don’t normally see are the micro-controlled precision stepper motors, solid state sensors for unparalleled accuracy, and user-customizable display feedback, all supported by an unrivaled limited lifetime warranty. The VHX Series has completely revolutionized the instrumentation industry! Dash cluster housing and console gauge housings are sold separately.

Please specify your desired finish for the instrument faces (carbon fiber or silver alloy) as well as the color desired for the display (blue or red) from the available drop-down menus. ( Speedometer & Tachometer in dash. Oil Pressure, Water Temp, Voltmeter & Fuel Gauge set in console gauge pod. )

PART NUMBER: DAS-1051

Displays included with this instrument system:
- Speedometer: 0-120/140/160 MPH analog depending upon application, 0-255 MPH/KPH digitally in message center.
- Tachometer: 0-8,000 analog, 0-9,990 digitally in message center.
- Oil Pressure: 0-80psi analog and digitally.
- Water Temp: 140-220°F analog, 0-300°F/ 0-150°C digitally in message center.
- Voltmeter: 0-17VDC analog and digitally.
- Fuel Level: Empty- Full analog. 0-99% digitally in message center.
- Also shown in the digital message center:
  - Odometer
  - Trip Odometer (A&B)
  - Resettable Service Odometer
  - Clock
  - Hour-meter
  - 0-60 MPH (0-100 KPH) timer
  - ¼ mile timer
  - ¼ mile speed display
  - High Speed recall
  - High RPM recall
Various Indicators can also be displayed such as:
- Turn Signals
- High Beam
- Check Engine
- Parking Brake
- Cruise Control
- 4x4 (when equipped) displayed in message center.
- Wait to Start (when equipped) displayed in message center.
Automatic Transmission gear indicator is also included which will display the full name (ie: Park, Overdrive, etc.) of the current gear. Utilizing the gear position indicator will require the use of a Dakota Digital GSS-2000 (sold separately) sending unit.
Dakota Digital instruments systems also include a Demonstration Mode which will cycle the instrument readouts while the vehicle is standing still. This is especially popular while the vehicle is on display at a show, event or simply displaying the instrument system.
Metric conversions will cycle between MPH or KPH in the digital message center with the press of a button. Full metric analog instrument systems (KPH & Celsius) are not currently available.
Necessary sensors included for oil pressure (1/8” NPT), Water Temp (1/8" with bushings for 1/4", 3/8", 1/2” NPT as well 12mm and 16mm for GM & LS applications) and speedometer pulse generator.
Fuel level gauge can read either OEM sensor, or any aftermarket style currently available. A universal fuel level sender, SEN-06-1, can be purchased from Dakota Digital if necessary.
Fully programmable speedometer for various tire sizes, rear-end gearing combinations, etc.
Built-in illumination is activated as headlights/ parking lights are activated. The DIM-1 can be purchased from Dakota Digital to increase or decrease the brightness of the display. The DIM-1 is used in conjunction with your headlight switch
Fully adjustable warning points alert the user of potential vehicle problems in the digital message center
One-time user settable odometer. This is available only within the first 100 miles of operation. Once exceeded, the mileage can be reset by Dakota Digital at a charge of $20.
